GIGABYTE Z890 Aorus Elite Wi-Fi 7 ICE,LGA 1851 DDR5 ATX Motherboard,4x Dimm Slot,Up To 256gb Max Memory,Wi-Fi 7 & BT 5.4,Pcie 5.0 X16, 4x M.2 Slot,White
GIGABYTE Z890 Aorus Elite Wi-Fi 7 ICE,LGA 1851 DDR5 ATX Motherboard,4x Dimm Slot,Up To 256gb Max Memory,Wi-Fi 7 & BT 5.4,Pcie 5.0 X16, 4x M.2 Slot,White
$139.90
GIGABYTE Z890 Aorus Elite Wi-Fi 7 ICE,LGA 1851 DDR5 ATX Motherboard,4x Dimm Slot,Up To 256gb Max Memory,Wi-Fi 7 & BT 5.4,Pcie 5.0 X16, 4x M.2 Slot,White—
$139.90
The Story
| CPU | LGA1851 socket: Support for Intel® Core™ Ultra Processors, L3 cache varies with CPU. Refer to "CPU Support List" for details. |
| Chipset | Intel® Z890 Express Chipset |
| Memory Support | DDR5 9200(O.C) to 5600MT/s memory modules, 4 x DDR5 DIMM sockets up to 256 GB (64 GB per DIMM), Dual channel, ECC & non-ECC un-buffered memory support. |
| Onboard Graphics | Intel® HD Graphics with Thunderbolt™ 4 (DisplayPort, Thunderbolt™ video output), HDMI, DisplayPort; supports up to triple-display. |
| Audio | Realtek® ALC1220 CODEC, High Definition Audio, 2/4/5.1/7.1-channel support, S/PDIF Out. |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication | MediaTek Wi-Fi 7 MT7925 or Realtek® Wi-Fi 7 RTL8922AE, Bluetooth 5.4, 11be 160MHz support. |
| Expansion Slots | 1 x PCI Express x16 (PCIe 5.0, CPU) and 2 x PCI Express x16 (PCIe 4.0, Chipset) |
| Storage Interface | 4 x M.2 connectors (PCIe 5.0/4.0 support), 4 x SATA 6Gb/s connectors, RAID 0, 1, 5, 10 for NVMe & SATA devices. |
| USB | Thunderbolt™ 4 (CPU), USB 3.2 Gen 2 and Gen 1 (Chipset), USB 2.0 via internal headers and back panel. |
| Internal I/O Connectors | 24-pin ATX power, multiple fan headers, RGB headers, M.2, SATA connectors, front panel audio, USB headers. |
| Back Panel Connectors | Thunderbolt™ 4, USB 3.2 Gen 2, USB 2.0, DisplayPort, RJ-45, S/PDIF Out, audio jacks, antenna connectors. |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, temperature, fan speed, water cooling flow rate, fan fail warning, fan speed control. |
| BIOS | 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Windows 11 64-bit |
| Form Factor | ATX, 30.5cm x 24.4cm |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
| CPU | LGA1851 socket: Support for Intel® Core™ Ultra Processors, L3 cache varies with CPU. Refer to "CPU Support List" for details. |
| Chipset | Intel® Z890 Express Chipset |
| Memory Support | DDR5 9200(O.C) to 5600MT/s memory modules, 4 x DDR5 DIMM sockets up to 256 GB (64 GB per DIMM), Dual channel, ECC & non-ECC un-buffered memory support. |
| Onboard Graphics | Intel® HD Graphics with Thunderbolt™ 4 (DisplayPort, Thunderbolt™ video output), HDMI, DisplayPort; supports up to triple-display. |
| Audio | Realtek® ALC1220 CODEC, High Definition Audio, 2/4/5.1/7.1-channel support, S/PDIF Out. |
| LAN | Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication | MediaTek Wi-Fi 7 MT7925 or Realtek® Wi-Fi 7 RTL8922AE, Bluetooth 5.4, 11be 160MHz support. |
| Expansion Slots | 1 x PCI Express x16 (PCIe 5.0, CPU) and 2 x PCI Express x16 (PCIe 4.0, Chipset) |
| Storage Interface | 4 x M.2 connectors (PCIe 5.0/4.0 support), 4 x SATA 6Gb/s connectors, RAID 0, 1, 5, 10 for NVMe & SATA devices. |
| USB | Thunderbolt™ 4 (CPU), USB 3.2 Gen 2 and Gen 1 (Chipset), USB 2.0 via internal headers and back panel. |
| Internal I/O Connectors | 24-pin ATX power, multiple fan headers, RGB headers, M.2, SATA connectors, front panel audio, USB headers. |
| Back Panel Connectors | Thunderbolt™ 4, USB 3.2 Gen 2, USB 2.0, DisplayPort, RJ-45, S/PDIF Out, audio jacks, antenna connectors. |
| I/O Controller | iTE® I/O Controller Chip |
| H/W Monitoring | Voltage, temperature, fan speed, water cooling flow rate, fan fail warning, fan speed control. |
| BIOS | 256 Mbit flash, AMI UEFI BIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | GIGABYTE Control Center (GCC), Q-Flash, Q-Flash Plus, Smart Backup |
| Bundled Software | Norton® Internet Security (OEM), LAN bandwidth management software |
| Operating System | Windows 11 64-bit |
| Form Factor | ATX, 30.5cm x 24.4cm |
